Product Description

Semiautomatic filling machine for Bag in Box can fill bag sizes starting from 2 to *0 liters.

The machine is equipped with:

•

  a control panel which manages the filling volume, the vacuum time, nitrogen time, to start the filler cleaning and also can be stored ormats customized according to your needs, finally giving a statistic of the work performed.

•

  vacuum switch with which is possible to realize the control faulty bags;

•

  an inclined surface adjustable with rollers (or smooth surface) to help the descent of the bag into the box;

•

  stainless steel frame on pivoting wheels, two of them with brake;

•

  surface adjustable in height for boxes placement;

•

  a system for nitrogen injection;

Machine designed for CIP cleaning and sterilization with hot water. Realized with materials suitable for chemical cleaning;

You can use any kind of taps for standard bag-in-box, such as: Vitop, Press-Top and Flex-Top

BOTTLING CYCLE :

You can place manually the Bag-in-Box in the fork; acting on the lever the cap is removed and the nozzle inserted into the bag.

Pressing the Start takes place the vacuum into the bag and then the filling with the addition of nitrogen.



Acting once again on the lever the cap is inserted in the Bag-in-Box and the bag is removed manually to slide it into the box.



The machine has a surface adjustable with rollers (or smooth surface) to help the descent of the bag into the box, that is placed on an surface adjustable in height

Bottling Hour Capacity :

Filler technical details :

• Pump power : 1,5 kW
• Supply : **0V monofase *0Hz
• Air pressure : 6 bar
• Nitrogen pressure : 0,5 bar
• Weight : *7kg
• Dimensions : 0,*0 x 0,*0 x 1,*0 metri
