1325 Wood CNC Router Machine with ATC

Product Description

NT****5ATC**0 Wood CNC Router with ATC
CNC Machining Center
Application:
Machine Character:
1.High speed gantry moving CNC machining center
2. Spindle adopts China 9.0KW air cooling ATC spindle or Italy 9.5KW air cooling
ATC spindle, ISO *0 tool handle, circular tool magazine with *0 pieces tools and
with Panasonic servo system.
3. The whole machine motor adopts Japan Panasonic big power servo motor, match
high precision imported reducer, extend machine's using life, high precision, high
speed and stable performance.
4. Machine's X Y Z axis adopts Taiwan HIWIN square liner rail, X/Y axis adopts
Taiwan XINYUE 1.5M high precision rack and pinion, Z axis adopts Taiwan TBI
C5 ball-screw transmission.
5. Taiwan SYNTEC controlling system, mutli-interface extension, support upgrading
on line, internet transmission, standard industry design, compatible with CAD,CAM
and other design software, suitable for 3D engraving and cutting quickly and smoothly.
Performance Parameter:
Working Table: ***0****0MM
Travelling Area: ***0****0MM
Feeding Height: **0MM
Spindle: China 9.0KW Air Cooling/Italy 9.5KW air cooling
Tool Handle: ISO *0
Voltage: **0V/*0HZ
Running Speed: *5M/min
Spindle Speed: ***0~****0RPM/min
Tool Diameter: Φ6 Φ*2.7
Command Code: G Code
Vacuum Power: 7.5KW
