HTU21D Miniature Relative Humidity and Temperature Sensor

Product Description

DESCRIPTION

HTU*1D(F), is a new digital humidity sensor with temperature output ofTESetting new standards in terms of size and intelligence, it is embedded in a reflow solderable Dual Flat No leads (DFN) package with a small 3 x 3 x 0.9 mm foot print. This sensor provides calibrated, linearized signals in digital, I²C format.

HTU*1D(F) digital humidity sensors are dedicated humidity and temperature plug and play transducers for OEM applications where reliable and accurate measurements are needed. Direct interface with a micro-controller is made possible with the module for humidity and temperature digital outputs. These low power sensor are designed for high volume and cost sensitive applications with tight space constraints.



Parameters:



1)storage temperature: **0 to **5oC

2)supply voltage: 3.8V

3)Humidity Operating Range: ****0%RH

4)Temperature operating range: **0 to **5oC

5)VDD to GND:*0.3 to 3.6V

6)Relative Humidity Accuracy: ±3%RH



Features:

(1)DFN type package

(2)Relative Humidity and Temperature Digital Output, I2C interface

(3)Fully calibrated

(4)Lead free sensor, reflow solderable

(5)Low power consumption

(6)Fast response time and very low temperature coefficient
