3 in 1 Ice Tea Filling Processing Line with Packing Machine and Water Treatment Equipment

3 in 1 Ice Tea Filling Processing Line with Packing Machine and Water Treatment Equipment

FOB Price

Get Latest Price

20000 ~ 500000 / Unit ( Negotiable )

|

Minimum Order

Place of Origin:

-

Price for Minimum Order:

Minimum Order Quantity:

1

Packaging Detail:

wooden case

Delivery Time:

50 working days

Supplying Ability:

50 Unit per Year

Payment Type:

T/T, L/C

Contact Now
Suzhou Labelong Packaging Machinery Co., Ltd

Suzhou Labelong Packaging Machinery Co., Ltd

China

Free Member

Contact Person Ms. Nelly

B18 LEYU Industry Zone, 215621, Zhangjiagang, Jiangsu

Contact Now

Description



High Quality and Low Price Fruit Juice Bottling Line/Lines for Small Pet Bottles


RFC-H series filling machines are designed especially for bottling synthetic juices (RTS) or HOT filled juices, tea (filled at up to 98 centigrade degrees), with optional capacity ranging from 1000BPH to 32000BPH, it adopts the pressure & rotative filling style.

The rinsing system, capping system rotor assemblies are identical to the non-carbonated beverage filling machine (RFC Series), however there are some additional smart features provided along with specially designed valves, designed specifically for the purpose.

Features present are as under:
1. Centre filling valves used which are designed for maximum flow rate and minimum bottle distortion during HOT filling.
2. Inbuilt CIP arrangement provided on the machine for fill tank and fill valve sanitation.
3. Dummy caps provided fitting on all filling valves during CIP.
4. Automatic PLC controlled valve washing cycle before commencement of every production cycle for overall hygiene.
5. Unique filling cam designs which prevents filling up to the bottle collar without spillage.
6. Bypass line provided for flushing the product fill tank after completion of CIP
7. Supper heavy stainless steel juice tank build in

Available Models of these series filling machine: (based on 500ml PET bottle)RFG-H-H 8-8-3 Capacity: 1500~2000BPH
RFG-H 16-12-6 Capacity: 2000~4000BPH
RFG-H16-16-6 Capacity: 4000~5000BPH
RFG-H18-18-6 Capacity: 4000~6000BPH
RFG-H24-24-8 Capacity: 6000~8000BPH
RFG-H-32-32-8 Capacity: 10000-12500BPH
RFG-H40-40-10 Capacity: 16000-20000BPH
RFG-H50-50-12 Capacity: 20000-24000BPH
RFG-H60-60-15 Capacity: 25000-30000BPH
