| Technical Parameter | ||
| Model | SL3QZ | |
| Note wax pattern | Adjustable cylinder | |
| Material forming | all kind of paraffin | |
| Finished wax block specification(mmm) | 480*300*50(L*W*H), 5kgs/block | |
| Wax disc group number (sets) | 380 | |
| Wax disc group rated speed (mm/min) | 1650 | |
| Rated production capacity | Hour capacity (kg/h) | 4670 |
| Yearly capacity (tons/8000h) | 37400 | |
| Main motor power (KW) | 5.5 | |
| Main chain model | LJ317 | |
| Cold room | Material | PU polyurethane color plate |
| Dimension (m) | 19*6.4*3.72 | |
| Cold fan evaporator | Structure style | double motors double fans |
| Quantity (pcs) | 4 | |
| Heat exchage area (m 2 ) | 850 | |
| Motor power (KW/pc) | 4 | |
| Intermittent discharge wax conveyor | Specification (mm) | 3000*6000 (L*W) |
| Structure style | Chain plate | |
| Power (KW) | 1.1 | |
| Discharge wax time (S) | 2.5 ~5 | |
| Max dimension (m) | 26.5*6.4*3.72(L*W*H) | |
| Weight (tons) |
about 58 |
|
