Description
Product Introduction
A kind of advanced vibrating screen with circular motion
Capacity
80～1700t/h
Product Improvement
Ring groove rivets connection, plate type screen box, advanced
structure, strong and durable
Vibration exciter with eccentric shaft and eccentric block, high
screening efficiency, large capacity
Advantages
Screen mesh is made of wear-resistant rubber with long service
life
Screen frame with high strength
Large clearance bearings operating with low temperature lift
Reasonable mechanical structure, low noise and high screening
efficiency
Ring groove rivets connection, advanced structure, strong and
durable
Large capacity, strong versatility of components and convenient
repair
Classification of screen mesh
Screen mesh is main wearing parts. According to the materials and
requirement of clients, there are manganese steel weaving meshes,
punching screens and rubber screen plates with single or double
layers.
According to the loading, wear-resistant screen mesh of Xinhai
round vibrating screen is divided into light screen mesh (HD60
rubber), medium screen mesh (HD 70 rubber), heavy screen mesh (HDS
rubber)
Product Description
Round vibrating screenadopts eccentric shaft vibration exciter and
eccentric block to adjust amplitude. The vibrator installed on the
sideboard of screen box forces screen box to vibrate by the driving
of motor. The sideboard of vibrating screen is made of high quality
steel plate. Connect sideboards, beams, and the exciter base by
high strength bolts or ring groove rivet. Vibrating screen adopts
seat installation, and screen angle can be adjusted by changing the
height of spring support.
The motor of round vibrating screen are installed on the right side
of screen box, and can also be installed on the left side of screen
box. If no special requirements, the motor is installed on the
right side.
Application
Round vibrating screen is applied in quarry for screening sandstone
or for product classification of coal, mine, construction
materials, electric power and chemical industry.
Technical Parameters
|
Model |
Screen Surface |
Max. Feed Size |
Capacity (t/h) |
Motor |
Weight (kg) |
|
Area (m2) |
Dip Angle (° ) |
Mesh Size (mm) |
(mm) |
Model |
Power (kW) |
|
YA1236 |
4.3 |
20 |
6~50 |
200 |
80~240 |
Y160M-4 |
11 |
4905 |
|
2YA1236 |
80~240 |
Y160M-4 |
5311 |
|
YA1530 |
4.5 |
80~240 |
Y160M-4 |
4675 |
|
YA1536 |
5.4 |
100~350 |
Y160M-4 |
5137 |
|
2YA1536 |
400 |
100~350 |
Y160L-4 |
15 |
5624 |
|
YAH1536 |
30~150 |
160~650 |
Y160M-4 |
11 |
5621 |
|
2YAH1536 |
30~150; 6~50 |
160~650 |
Y160L-4 |
15 |
6045 |
|
YA1542 |
6.5 |
6~50 |
200 |
110~385 |
Y160M-4 |
11 |
5515 |
|
2YA1542 |
6~50 |
110~385 |
Y160L-4 |
15 |
6098 |
|
YA1548 |
7.2 |
6~50 |
120~420 |
Y160L-4 |
5918 |
|
2YA1548 |
6~50 |
120~420 |
Y160L-4 |
6321 |
|
YAH1548 |
7.2 |
30~150 |
400 |
200~780 |
Y160L-4 |
6842 |
|
2YAH1548 |
7.2 |
30~150 ； 6~50 |
200~780 |
Y160L-4 |
7404 |
|
YA1836 |
6.5 |
30~150 |
200 |
140~220 |
Y160M-4 |
11 |
5205 |
|
2YA1836 |
6.5 |
30~150 |
140~220 |
Y160L-4 |
15 |
5946 |
|
YAH1836 |
6.5 |
30~150 |
400 |
220~910 |
Y160M-4 |
11 |
5900 |
|
2YAH1836 |
6.5 |
30~150; 6~50 |
220~910 |
Y160L-4 |
15 |
6353 |
|
YA1842 |
7.6 |
6~150 |
200 |
140~490 |
Y160L-4 |
15 |
5829 |
|
2YA1842 |
7.6 |
6 ~150 |
140~490 |
Y160L-4 |
15 |
6437 |
|
YAH1842 |
7.6 |
30~150 |
400 |
450~800 |
Y160L-4 |
15 |
6352 |
|
2YAH1842 |
7.6 |
30~150 ； 6~50 |
450~800 |
Y160L-4 |
15 |
7037 |
