60t Portable Truck Scales for Axle Weight

Product Description

Introduction of this Portable Truck Weight Scale for Axle Weight.

The portable truck weight scales are simple to use, require no a foundation, and is easy to move, which is so welcome.

• Indicator : 1pcs
• Weighing platform :   2pcs
• Ramps-Guide plate :  4pcs

Product Parameters
Technical Specification-

1. Table size: 3, 3.2, 3.5, 4.0m, etc × 0.9, 2.0, 2.2, 2.5, 3.0 m and other specifications;
2. Load cells: four 20 ton (or 30 ton) load cells;
3. Scale range specification: 20, 30, 40, 50, 60, 80, 100t;
4. Static accuracy: OIML Class III, d=10, 20, 50kg; Dynamic accuracy: axle weight class F, total weight class 5
5. Weighing method: total weight=cumulative weight of front and rear wheels, and the whole vehicle can weigh up to 50~150 tons;
6. Use power supply~220V/50Hz (equipped with rechargeable battery, it can also be used in case of power failure!)
7. It is equipped with micro printer to print weighing results;
8. Foundation is required; Weighing at fixed position; The length of flat ground is required to be more than twice the vehicle length!

Advantages of the product-Portble Truck Scales.

Steel structure, which can be fixed on site, can be easily moved by forklift when it needs to be moved, without foundation;The weighing table adopts a structural form in which multiple sealing sensors are embedded at the bottom of the steel weighing table, with high weighing accuracy and excellent sealing.

Applications

• Simple truck axle scales: used for raw material storage, cumulative output, internal settlement, etc. Due to the use of axis measurement, the external dimensions of the weighing platform are much smaller than ordinary truck scales, and the floor space is correspondingly much smaller, so the investment is very low. Less; because the equipment is light in weight and easy to move, it also saves installation and transportation costs.
• Checking overloading and overloading: It can be used as a device for traffic control and road administration departments to check overloading and overloading of cars on the highway, which is crucial for safe driving and protection of roads and bridges.
• Safety performance testing: It can be used as a car safety performance testing line to detect the wheel (axle) weight of the car. It mainly uses its dynamic method, which not only saves the installation site of the testing line (actually also saves site investment), but also saves space due to the use of dynamic testing. The detection time is greatly shortened and the detection efficiency is improved.

Generally used for material weighing in industries such as buildings, forestry, energy, metallurgy, environmental protection (waste disposal), factories and mines, logistics, etc. with small footprint, low requirements for basic construction, and diverse types of automobiles.
