SC/FC/ST/LC Single-core Dual-core Patch Cords LC Uniboot
Passive Optical Patch Cords
Compared to OM1/0M2, OM3, OM4 and OM5 optical fibers are
suitable for high bandwidth:
Not exceeding **0 short-distance to medium-distance
communications, while OS2
(G.**2.D/G.**7.A1/G.**7.A2/G.**7.B2/G.**7.B3) optical fiber
types are suitable for long-distance, high-performance
communication systems.
Features:
Provide a variety of connector types, with more choices for
Class B/C/D, and competitive cost
Ceramic ferrule has an average of more than 1,**0 plug-in
and pull-out tests, with stable performance and reliable
quality.3.Excellent mechanicaendurance
Color-Coded Connector Boots for Easy Identification
Corning ClearCurve® YOFC Fiber with *0mm Min. Bend Radius
Available OFNR、OFNP、CPR(B1ca/B2ca/Cca/Dca/Eca)
Available in single sheath (2.0mm to 3.0mm, typically
overall length ≤*5m) and double sheath (4.5mm to 5.5mm)
RoHS2 Certification
Technical Parameters:
Connector A LC Connector B LC
Polish Type UPC to UPC Glass Fiber Corning Clear Curve®
Fiber Mode OS2 SMF 9/**5μm Wavelength **0/***0nm
Fiber Count 1 Fiber Polarity
Cable Outside Diameter(OD) 0.9mm,2.0mm,3.0mm Cable Jacket
Plenum(OFNP)
Min.Bend Radius(Optical Fiber) 7.5mm Min.Bend Radius (Fiber
Cable) *0/*0D(Dynamic/Static)
Connector Durablity **0 times Tensile
Strength(Long/ShortTerm) *0/**0N
Insertion Loss 0.*5dB Max(0.*5dB Typ.) Return Loss ≥*0dB
Attenuation at **0nm ≤2.3dB/km Attenuation at***0nm
≤0.6dB/km
Operating Temperature **0 to *0℃(*4 to **8F) Storage
Temperature **0 to *5℃
Glass Fiber Corning, YOFC Operating Temperature **0 to
**0°C
Applications:
1. Telecommunications
2. CATV, LAN, MAN, WAN, Test &Measurement
3. Military industry
4. Medical
Fiber optic patch cords ensure seamless and stable
connections between your servers, workstations, and other
hardware with specific lengths of single-mode or multimode
fiber cables. If you are choosing duplex fiber cables, they
definitely have the appropriate micron fiber for high
bandwidth and high-speed data transmission on gigabit
Ethernet. There are various technical differences between
different sizes and types of fiber cables, so you must
first understand these differences to select the best
options online. Today, you can purchase LC cables, SC
cables, OM3 cables, and OM4 cables from our store.
