Multi-function Integrated Optic Chip for Gyroscope (Y waveguide modulators)
Model: MIOC-13-09-XX-N
Description
Idealphotonics LiNbO3 multi-function integrated optical chip (MIOC) is manufactured by micro-electronics technology. There are several cells integrated on the same chip, include polarizer, splitter /combiner, phase modulator, etc.
Feathure
X-Cut, y-propagating LiNbO3
Very low insertion loss.
APE process for waveguide, works in single polarization
High extinction ratio
Fiber is sloping coupled with waveguide, which deduce optical return far and away
Push-pull electrode design may deduce half wave Voltage
Small packaging and lightweight
Excellent long-term stability
Application
Fiber optic gyroscopes (FOG).
Fiber optic current senser(FOCS)
Hydrophone and other optic sensitive fields
It is for attitude control of movements such as aircrafts, ships, guided missiles, automobiles etc in the fiber gyroscope system, Hydrophone and other optic sensitive fields. Faraday Effect was used to measure current through fiber circuit in the current sensing system.
Chip structure：
|
|
| Parameter | Unit | Values |
| Wavelength | nm | 1310 |
| Insertion | dB | ≤4.0 |
| Half wave Voltage | V | ≤4.0 |
| Splitting Beam Ratio | - | 47/53－53/47 |
| Optical Return | dB | ≥50 |
| Polarization extinction ,chip | dB | ≥55 |
| Additional Intensity Modulating | - | ≤0.2% |
| PM Pigtail Crosstalk | dB | ≤-30 |
| Electrode type | - | Push-pull modulating |
| Bandwidth | MHz | ≥300 |
| Pigtail type | - | PM |
| Work temperature | ℃ | -40～+70 |
| Packaging dimensions | mm | 30X8X5 or 35X10X5 |
| Type | Description |
| MIOC-13-09-09-N | 1310nm integrated optical chips ( Y waveguide) /output: 125/250um PM fiber, 1m fiber length, without connector |
| MIOC-13-09-80-N | 1310nm integrated optical chips ( Y waveguide) : 125/250um PM fiber, output with 80/165um PM fiber, 1m fiber length, without connector |
