Eternal 400X Optical Fiber Inspection Video Probe Kits FVO-730B-V

China

FVO-730B-V

Get Latest Price

-

-

1 Box

-

5 days

100 Box per Week

PayPal, Western Union, D/A, L/C, T/T

Fiber Probe

Contact Now

Product Specification

Magnification Ability : 400x Weight : 0.650 Kilogram Size : 27 Centimeters * 15 Centimeters * 12 Centimeters

Product Description

FVO-730B-V microscope is the upgraded version of FVO-700A-V which provides network personnel with high performance fiber inspection solutions. The whole set includes a analog probe FVO-730B, VSM-380 monitor with the capability to inspect/record/file the data of fiber end face from assorted connectors.

Specifically, FVO-730B probe can not only detect ferrule end of patch cord, but also the fiber end face mounted into the bulkhead adapters with PC/APC end. Connectors even installed at the bottom of patch panels or inside hardware devices can be also easily accessed and inspected without any removal or disassembling of equipment with specific or customized tips.

Compared with the traditional probe, its unique one-way focus control in the FVO-730B probe greatly simplifies the work. No matter left or right hand, forward or reverse operation, it can instantly have the end face inspected and image displayed, save more time for efficiency. The probe can offerring clients the greatest value to save cost and convenience.

VSM-380A monitor equipped with the probe is the upgraded version of VSM-360 for real on-the-go inspection. New Monitor can be carried along the wrist whenever and wherever for the greatest convenience of image data review and file. New functions like notification sounds, standard output connector etc., are added on for the upgrade while traditional features are hold unchanged as capture/record/store etc., to further handy the operation.



Key feature



  • One-way focus control for instant detection, have image in seconds.
  • Precise resolution(<1μm), no shadow or dark edge around screen.
  • Bright and Contrast Adjustment for indoors/outdoors operation.
  • 2.7 Inch Monitor support in Video record/Voice editing/Image Capture/File Generated .
  • 35 assorted of tips available to have both PC and APC end face inspection.
  • 60°angle tips to test multiple types of connectors in many hard-to-access places or bottom of patch panel.
  • Ability to inspect MPO/MTP etc PC and APC multiple cores end face.
  • Precise cone contact to reach 98% alignment consistency.
  • Large capacity TF card inside the monitor can be easily access to PC or laptop. Optional Software Function for end face data analyze and judgment based on different IEC criteria.





Specification



Component

Arguments

Value



FVO-730B Probe

Magnification/Resolution



400× / 0.75μm (Based on 8 Inch monitor)



Focus way / Range



One-way / <3mm



View of Field(mm)



0.3011*0.2273



Tips Connection



Cone contact



Light Source/ Life time



Coaxial blue LED / 100,000 hrs above



Size/Weight



180*41*36mm/ 0.50kg



Storage Temperature



-20~50 degree



Humidity



Maximum to 90% relative humidity, no condenses

2.7 Inch Display


Image size(mm)

22





Pixel

307200



Video

Frame rate

25FPS





2.7 Inch Display

640x480 Pix





Video Output Mode

NTSC/PAL





Output file format

AVI



Internal Memory

Memory Card

TF





Capacity

8GB





USB

USB1.1/2.0





Disk Format

FAT32



Power Supply

Adapter

DC 5V 600mA





Battery Volume

Lithium 1800mAh





Continued Working Hours(h)

2



Size/Weight



78*22*56mm / 0.085kg

EFD Version Data Analyze Software

    • Verification of Fiber end face quality, pass or fail judgment based on standard international criterion or setting by user.
    • Pdf or Excel Report file generated to have scratch, spot etc defects measured and counted around the fiber end face.
    • Analyze Support in image, video and real-time inspection.







Purchase Guide



Item

Quantity (pcs)

Standard Configuration

FVO-730B Probe

1



2.7 Inch Display

1



Standard tips: SC-P-F,FC-P-F,LC-P-F,2.5mm-M

1 respectively each type



12V Power Cord

1



Earphone Wire

1



USB Wire

1



Vedio Wire

1



TF Card&Reader

1
